Model: ASH52D27H3G
Diameter: 52mm
Height: 27mm
Angle: 3°
Material: PMMA+PC
Transmittance: >93%
LED Type: Cree XPE-2
Lighting Applications: surgical light
Distribution
Specifications
| Model: | ASH52D27H3G |
| Diameter: | 52mm |
| Height: | 27mm |
| Angle: | 3° |
| Material： | PMMA+PC |
| Transmittance： | >93% |
| LED Applications | Cree XPE-2 |
| Lighting applications | surgical light |
LED Type
XPE2
Packaging
---Material Information
Lens Material
L06: PMMA 8N/ L46: PC 1250Z
Operating Temperature
PMMA:-40°C~ +80°C/ PC: -40°C~ +120°C
UL Flammability
PMMA: [email protected]/ PC 1250Z: V-2 @1.5mm
UL RTI Elec
PMMA: 90°C @1.5mm/ PC 1250Z: 125°[email protected]
Light Transmission Rate
400nm ~ 900nm>90%
If necessary, Clean lenses with mild soap, water and soft cloth.
Never use any commercial cleaning solvents on lenses, like alcohol.
Please handle or install lenses with wearing gloves, skin oils may damage lens or its optical characteristic.
