Model: UFO226D60G, 90G, 120G-150W-B26
Diameter: 226mm
Height: 9.8mm
Angle: 60°,90°,120°
Material: PC-1250Z TEIJIN
Transmittance: >88%
LED Type: 2835/3030LED
Lighting Applications: High Bay Lighting, Area Lighting
1.The IP66 Waterproof 150W UFO Industrial Lighting Lens with a 3030 LED configuration and a 60/90/120-degree beam angle is suitable for industrial lighting applications that require powerful and focused illumination.
2.Its waterproof design and durable construction make it suitable for use in outdoor or harsh environments where protection against water and dust is essential.
Distribution
Specifications
| Model: | UFO226D60G, 90G, 120G-150W-B26 |
| Diameter: | 226mm |
| Height: | 9.8mm |
| Angle: | 60°,90°,120° |
| Material： | PC-1250Z TEIJIN |
| Transmittance： | >88% |
| LED Applications | 2835/3030LED |
| Lighting applications | High Bay Lighting, Area Lighting |
LED Type
OSRAM OSCONIQ® P
LUXEON 3030 HE
NFSW 3030 series
XI3030 series
EMC 3030 series
Packaging
---Material Information
Lens Material
L06: PMMA 8N/ L46: PC 1250Z
Operating Temperature
PMMA:-40°C~ +80°C/ PC: -40°C~ +120°C
UL Flammability
PMMA: [email protected]/ PC 1250Z: V-2 @1.5mm
UL RTI Elec
PMMA: 90°C @1.5mm/ PC 1250Z: 125°[email protected]
Light Transmission Rate
400nm ~ 900nm>90%
If necessary, Clean lenses with mild soap, water and soft cloth.
Never use any commercial cleaning solvents on lenses, like alcohol.
Please handle or install lenses with wearing gloves, skin oils may damage lens or its optical characteristic.
ASAHI OPTICS UFO226D60G, 90G, 120G-150W-B26 lens 3D drawing.STP
ASAHI OPTICS UFO226D60G,90G,120G-150W-B26 Drawing.dwg
ASAHI OPTICS UFO226D60G,90G,120G-150W-B266 Drawing.pdf
ASAHI OPTICS UFO226D60G-150W-B26 lens IES.ies
ASAHI OPTICS UFO226D90G-150W-B26 lens IES.ies
ASAHI OPTICS UFO226D120G-150W-B26 lens IES.ies
