Model: AJHB180D36LED30G
Diameter: 180mm
Height: 11.0mm
Angle: 30°
Material: PC
Transmittance: >90%
LED Type: 3535LED
Lighting Applications: High Bay lighting
1. High Power lens module for Floodlight, with completely optical beam angles 10°, 15°, 30°, 45°, 60°，90°.
2. This high power lens module is designed for 3535LED size with IP66 waterproof gasket and waterproof up to IK10.
Specifications
| Model: | AJHB180D36LED30G |
| Diameter: | 180mm |
| Height: | 11.0mm |
| Angle: | 30° |
| Material： | PC |
| Transmittance： | >90% |
| LED Applications | 3535LED |
| Lighting applications | High Bay lighting |
1. High Power lens module for Floodlight, with completely optical beam angles 10°, 15°, 30°, 45°, 60°，90°.
2. This high power lens module is designed for 3535LED size with IP66 waterproof gasket and waterproof up to IK10.
