16in1 Lens Array 3030LED 60degree Wide-area Light Optics

Model: ALD50D16LED60G

Size: 50.0mm+50.00mm

Height: 5.61mm

Angle: 60°

Material: PC-1250Z TEIJIN

Transmittance: >93%

LED Type: 3030 LED

Lighting Applications: Architecture lighting,High Bay lighting,Stadium lighting

1. 50mm 16in1 array lens 60degree， compatible with 3030LED light source. It usually have high brightness and energy efficiency.

2. Through the combination of 16 LED lamp beads, the lens array can provide high-brightness lighting effects, making the lighting area brighter.

3. The angle of 60 degrees is moderate and can achieve more precise beam control. This design is suitable for places that require limited range lighting, and can focus the light within the target area to provide accurate lighting effects.

Specifications

Model:	ALD50D16LED60G
Diameter:	50.0mm+50.00mm
Height:	5.61mm
Angle:	60°
Material：	PC-1250Z TEIJIN
Transmittance：	>93%
LED Applications	3030 LED
Lighting applications	Architecture lighting,High Bay lighting,Stadium lighting

Light Distribution Curve

ISOCANDELA DIAGRAM ALD50D16LED60G

High Bay Lens 2 1

Drawing ALD50D16LED60G

LED LENS Maintenance Instruction

1) If necessary, clean lenses with mild soap, water, and softening cloth.
2) Never use any industrial solvent to clean lens, such as cleaning Solvent, Alcohol Sulfuric acid, Ammonia, Urea, Mineral oil, Petrol
3) The lens operating Temperature range -40°to+120°C
4) Alternatively the following environment is recommended: Storage temperature: -40°C to +70°C, Humidity:30% to 95% HR mar.
5) The lens has concentrated function, and it’s made from transparent material, The functions will be affected once they were polluted, so please do not open the packages until you use them, in case of dust and other pollution.
6) Please handle or install lens with wearing gloves, skin oils may damage lens optical characteristic.
